Advantech 4-channel Relay Output Modbus TCP Module with 4-channel DI (ADAM-6266-B)
Rp4.724.160
In Stock
Deskripsi
| Category | Attribute | Value |
| General | Connectors | 2 x RJ45, 1 x 15-pin plug-in screw terminal, 1 x 5-pin plug-in screw terminal |
| Protocol | Modbus/TCP, TCP/IP, UDP, HTTP, DHCP, MQTT, SNMP, ASCII command | |
| Communications | Interface | Ethernet |
| Isolated Digital Output | Channels | 4 |
| Input Voltage | Dry Contact Logic level 1: close to DI COM Logic level 0: open Wet Contact Logic level 1: 10~30 VDC and -10~-30 VDC Logic level 0: -3~3 VDC | |
| Environment | Isolation Voltage | 2,500 VDC |
| Operating Temperature | (-40~70 °C)(-40~158 °F) | |
| Relay Output | Channels | 4 |
| Contact Rating (Resistive) | 5 A @ 30 VDC, 5 A @ 250 VAC | |
| Relay Type | 1 x Form C | |
| Power Requirements | Input Voltage | 10~30 VDC |
