Advantech 4th Gen Intel®Core™ i5-4300U Mini-ITX w/eDP/DP/DP++, 2 COM, and Dual LAN (AIMB-230G2-U5A1E)
Harga hubungi kami
Deskripsi
| Category | Attribute | Value |
| Display | Controller | Intel Processor Integrated |
| Display | DDI (HDMI/DVI/DisplayPort) | HDMI : 1920 x 1080 @ 60Hz |
| Display | Graphic Engine | DirectX 11.1, OpenGL 4.0, OpenCL 1.3, Full AVC, VC1, MPEG2 H/W encoder |
| Display | Graphic Memory | Share with system memory,2 GB and above |
| Display | LCD (TTL/LVDS/eDP) | LVDS: Dual channel 24-bit LVDS, up to 1920 x 1080 |
| Display | Multiple Display | Dual/ Triple |
| Display | Video Interface | HDMI+LVDS (eDP), HDMI+DP++, LVDS (eDP)+DP++ |
| Form Factor | Form Factor | mini ITX |
| I/O | COM Port | 2 ( 1 x RS232, 1 x RS232/ 422/ 485) |
| I/O | Smart Fan | 2 |
| I/O | USB2.0 | 2 |
| I/O | USB3.0 | 4 |
| Memory | Max. Capacity | 16 GB |
| Memory | Socket | 2x 204 PIN SODIMM |
| Memory | Technology | DDR3L 1333 MHz |
| Processor | BIOS | AMI EFI 128Mbit |
| Processor | Chipset | Wildcat Point-LP |
| Processor | Core Number | 2 / 4 |
| Processor | CPU | Intel Core i5-4300U |
| Processor | CPU TDP | 15 W |
| Processor | Frequency | 1.8 GHz / 1.7 GHz |
| Processor | L3 Cache | 3 MB |
| Storage | CFast | 0 |
| Storage | mSATA | miniPCIe co-lay mSATA |
| Storage | SATA | 3 x SATA III (Max. Data Transfer Rate 600 MB/s) |
| Operating System | iManager | Yes |
| Operating System | Linux | Yes |
| Operating System | Microsoft Windows | Yes |
| Operating System | SUSIAccess | Yes |
| Environment | Operational Temperature | 0 ~ 60° C (32 ~ 140° F) |
| Environment | Vibration Resistance | 1 Grm (OP) |
| Power | Connector | DC 12V Jack/ 4-pin with ATX12V |
| Power | Power Adaptor | Yes |
| Power | Power Type | ATX, AT |
| Ethernet | Connector | RJ45 x 2 |
| Ethernet | Controller | GbE1: Realtek RTL8111E; GbE2: Realtek RTL8111E |
| Ethernet | Speed | 10/ 100/ 1000 Mbps |
| Audio | Audio Interface | HD Audio |
| Audio | CODEC | Realtek ALC892, High Definition Audio (HD) |
| Audio | Connector | 2 (Line out, Mic In) |
| Watchdog Timer | WatchDog Timer | Yes |
| Certification | EMC | CE, FCC |
| Certification | Safety Certifications | CCC/BSMI |
| Expansion | Slot Type | 1 x Full-size (Supports mSATA) 1 x Half-size |
| Expansion | Slots | Full-size Mini-PCIe, Half-size Mini-PCIe |
| Physical | Construction | Thermal moudle or CPU cooler |
| Physical | Dimension (mm) | 170 x 170 mm |
| Physical | Weight | 1.04 kg (1.72 lb), weight of total package |
Informasi Tambahan
| Brand | Advantech |
|---|
