Advantech CIRCUIT BOARD, Intel® Atom™ E3900 / Pentium® / Celeron® SOM-2569 N Series SMARC Module (SOM-2569BNBCA-S7A1)

SKU: SOM-2569BNBCA-S7A1 Kategori: Advantech, Boards & Cards, COM-Express, IoT / Industrial Tag: advantech

Deskripsi

Category	Attribute	Value
Display	DP/HDMI	1DP and HDMI
Display	LVDS	2 channels 18/24-bit, up to 1920 x 1200 @ 60Hz
Display	Triple Display	Yes
Form Factor	Form Factor	SMARC2.0 & SMARC2.1 Compliance
I/O	COM Port	4 Ports
I/O	GPIO	12
I/O	SATA	1
I/O	USB2.0	6
I/O	USB3.0	2
Memory	Channel/ Socket	Dual Channel / On Board Memory
Memory	ECC Support	No
Memory	Max. Capacity	4GB
Memory	Technology	Onboard LPDDR4-2400
Processor	BIOS	AMI UEFI BIOS at 64 Mb
Processor	Core Number	4
Processor	CPU	Intel Atom® x7-E3950 Processor
Processor	Frequency	1.6 GHz
Processor	LLC	2MB
Processor	Max Turbo Frequency	2 GHz
Environment	Operating Temperature	0 ~ 60° C (32 ~ 140° F)
Environment	Storage Temperature	-40 ~ 85° C (-40~185° F)
Power	Power Supply Voltage	Vin: 4.75-5.25V, RTC Battery: 2.0V ~ 3.3V
Power	Type	ATX: Vin, VSB; AT: Vin
Graphics	Controller	Intel® HD Graphics 505
Graphics	Graphic Memory	Intel DVMT5.0
Graphics	Max. Frequency	650MHz
Environment	Relative Humidity	40° C @ 95%, Non-Condensing, operating; 60° C @ 95%, Non-Condensing, non-operating
Expansion	PCle x1	Up to 4 PCIe x1
Mechanical	Dimensions	82 mm x 50 mm
WiFi Module	Wifi / BT Module	1 Wifi / BT Module on Board
Serial Bus	I2 C Bus	Yes
Serial Bus	SMBus	Yes
