Advantech CIRCUIT BOARD, miniITX LGA1151.VGA/DP/DVI/LVDS/PCIe/2GbE (AIMB-205G2-00A1E)
Deskripsi
| Category | Attribute | Value |
| Display | Controller | CPU Integrated |
| Display | DDI (HDMI/DVI/DisplayPort) | DVI-D/DP/VGA |
| Display | Graphic Engine | Intel HD Graphic |
| Display | Graphic Memory | Share with system memory up to 2 GB |
| Display | LVDS | 48-bit LVDS up to 1920 x 1200 at 60Hz |
| Display | Multiple Display | Dual |
| Display | Video Interface | DP/DVI-D/VGA support dual display |
| I/O | COM Port | 7 x RS-232, 1 x RS-232/422/485 |
| I/O | GPIO | 8-bit |
| I/O | TPM | Optional |
| I/O | USB2.0 | 6 |
| I/O | USB3.0 | 4 |
| Memory | Max. Capacity | 32GB (up to 16GB per SO-DIMM) |
| Memory | Socket | 2 x 260 Pin DDR4 SO-DIMM |
| Memory | Technology | DDR4 2133MHz SO-DIMM |
| Processor | BIOS | AMI EFI 128Mbit |
| Processor | Chipset | Intel H110 |
| Processor | Core Number | 4 / 2 |
| Processor | CPU | 6th Gen. Intel Core i7/i5/i3 Series Prosssor |
| Processor | CPU TDP | 65W / 35W |
| Processor | Frequency | 2.3G~3.4GHz |
| Processor | L3 Cache | 2 ~ 8MB |
| Storage | CFast | 0 |
| Operating System | Linux | Yes |
| Operating System | Microsoft Windows | Yes |
| Operating System | SUSIAccess | Yes |
| Environment | Non-Operational Temperature | -40~ 85° C |
| Environment | Operational Temperature | 0 ~ 60° C (32 ~ 140° F) |
| Environment | Vibration Resistance | 3.5 Grm (Non-Operation Mode) |
| Power | Connector | ATX20P |
| Power | Power Type | ATX |
| Ethernet | Connector | RJ45 x 2 |
| Ethernet | Controller | LAN1/ LAN2: Realtek RTL8111G |
| Ethernet | Speed | 10/ 100/ 1000 Mbps |
| Audio | Audio Interface | HD Audio |
| Audio | CODEC | Realtek ALC892, High Definition Audio (HD) |
| Audio | Connector | 3 (Line-in, Line out, Mic-in) |
| Watchdog Timer | WatchDog Timer | Yes |
| Certification | EMC | CE, FCC |
| Expansion | PCI Express x 16 | 1 |
| Expansion | Slot Type | 1 (F/S, mSATA support);1 M.2 (B-key) |
| Expansion | Slots | PCIex16,mini-PCIe, M.2 |
| Physical | Construction | with CPU cooler design |
| Physical | Dimension (mm) | 170x 170 mm (without heatsink) |
| Physical | Weight | 1.04 kg (1.72 lb), weight of total package |
Informasi Tambahan
| Brand | Advantech |
|---|
