Advantech NXP i.MX8M Plus Edge AI Box Computer (EPC-R3720IQ-ALA100)

SKU: EPC-R3720IQ-ALA100 Kategori: Advantech, ARM/RISC Solutions, Boards & Cards, IoT / Industrial Tag: advantech

Deskripsi

Category	Attribute	Value
Display	Graphic Engine	GC7000UL with 2D/3D Graphic Acceleration supporting 1G Pixel/s, OpenVG 1.1, Open GL ES3.1, Vulkan, and Open CL 1.2 FP.
Display	H/W Video Codec	Decoder: 1080p60 HEVC/H.265 Main, VP9 Profile 0/2, VP8, AVC/H.264 Baseline/Main/High Encoder: 1080p60 AVC/H.264, HEVC/H.265
Display	HDMI	Up to 3840 x 2160 at 30Hz
Display	LVDS/MIPI-DSI	1 4-Lane MIPI-DSI or 2 Single Ch. LVDS or 1 Dual Ch. LVDS
I/O	CAN	1 CAN-FD
I/O	UIO40-Express	1 RS-232, 4DI/4DO, 1 RS-485
I/O	USB	1 USB 3.2 Gen1 By 1, 1 USB 2.0
Memory	Capacity	Onboard 6GB
Memory	Flash	16 GB eMMC NAND Flash for O.S. and 8 MB QSPI NOR for board information
Memory	Technology	LPDDR4 4000MT/s
Processor	CPU	NXP ARM® Cortex®-A53 i.MX 8M Plus Quad
Operating System	Linux	Yocto Linux, Ubuntu and Android
Ethernet	Chipset	2 x NXP i.MX8M Plus integrated RGMII
Environment	Temperature (Operating)	-40~70°C
Indicator	LED	1 Power LED, 1 Programmable LED
AI Engine	NPU	2.3 TOP/s Neural Network Performance
