Cisco Aggregation Series Router ASR1006-20G-SEC/K9
Rp1.849.815.000
Cisco Aggregation Series Router ASR1004-20G-SEC/K9
Rp1.648.350.000
Cisco Aggregation Series Router ASR1006-10G-SEC/K9
Rp1.703.295.000
Deskripsi
ASR1006-10G-SEC/K9 Specification |
|
| General | |
| Device Type | Router |
| Enclosure Type | Desktop – modular – 6U |
| Connectivity Technology | Wired |
| Remote Management Protocol | SNMP, Telnet, SSH |
| Features | Firewall protection, NAT support, VPN support, MPLS support, IPv6 support, Stateful switchover (SSO), Quality of Service (QoS), MPLS VPN |
| Compliant Standards | CISPR 24, EN55022, VCCI Class A ITE, EN55024, CISPR 22, EN50082-1, CSA 22.2 No. 60950, EN 61000-6-1, AS/NZS 60950-1, AS/NZ 3548 Class A, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1 |
| Expansion / Connectivity | |
| Interfaces | Management: 1 x 10Base-T/100Base-TX – RJ-45 ¦ Management: 1 x console – RJ-45 ¦ Management: 1 x auxiliary – RJ-45 |
| Expansion Slots | 2 (total) / 1 (free) x processor board ¦ 17 (total) / 15 (free) x expansion slot |
| Installed Modules Qty (Max) | 3 (installed) / 19 (max) |
| Power | |
| Power Device | Internal power supply |
| Power Redundancy | Yes |
| Installed Qty | 2 (installed) / 2 (max) |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Software / System Requirements | |
| OS Provided | Cisco IOS Advanced Enterprise Services |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 21.9 in |
| Height | 10.5 in |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 – 90% |
