Ruijie RG-AP720-I Wireless Access Point
Harga Hubungi Kami.
| Model |
RG-AP720-I |
|
| Target Deployments |
For campuses, offices, hospitals, and hotspots of service providers |
|
|
Basic Specifications |
Radio |
Concurrent dual-radio dual-band |
| Protocol |
802.11a/b/g/n/ac |
|
|
Wave 2 |
||
| Operating Bands |
802.11b/g/n: 2.4GHz to 2.483GHz |
|
|
802.11a/n/ac: 5.150GHz to 5.350GHz, 5.47GHz to 5.725GHz, 5.725GHz to 5.850GHz (vary depending on countries) |
||
| Antenna |
Built-in Smart Antenna |
|
|
2×2 MU-MIMO |
||
| Max Throughput | ||
|
867Mbps@5GHz |
||
|
1267Mbps per AP |
||
| Spatial Streams |
2 |
|
| Modulation |
OFDM: BPSK@6/9Mbps |
|
|
QPSK@12/18Mbps |
||
|
16-QAM@24Mbps |
||
|
64-QAM@48/54Mbps |
||
|
DSSS: |
||
|
DBPSK@1Mbps |
||
|
DQPSK@2Mbps |
||
|
[email protected]/11Mbps |
||
|
MIMO-OFDM: |
||
|
BPSK, QPSK, 16QAM, 64QAM and 256QAM |
||
| Receiver Sensitivity |
11b：-91dBm(1Mbps)，-88dBm(5Mbps)，-85dBm(11Mbps) |
|
|
11a/g：-89dBm（6Mbps），-80dBm（24Mbps），-76dBm（36Mbps），-71dBm（54Mbps） |
||
|
11n：-83dBm@MCS0，-65dBm@MCS7，-83dBm@MCS8，-65dBm@MCS15 |
||
|
11ac HT20：-83dBm（MCS0）, -57dBm（MCS9） |
||
|
11ac HT40：-79dBm（MCS0）, -57dBm（MCS9） |
||
|
11ac HT80：-76dBm（MCS0）, -51dBm（MCS9） |
||
| Maximum Transmit Power |
100mw |
|
| Adjustable Power |
1dBm |
|
| IP Rating |
IP41 |
|
|
Ports |
Service Port |
2 10/100/1000BASE-T Ethernet ports (LAN1 port supports PoE & Uplink) 1 USB port |
| Management Port |
1 console port |
|
|
Power |
Power Supply | Local power supply (DC 48V) and PoE+ (802.3af/at) |
| (DC Power adapters should be purchased from third-party vendors separately if needed.) | ||
| Power Consumption |
<12.95W |
|
| WLAN | Maximum clients per AP |
Up to 256 |
| BSSID capacity |
Up to 16 per radio Up to 32 per AP |
|
| SSID hiding |
Support |
|
| Configuring the authentication mode, encryption mechanism and VLAN attributes for each SSID |
Support |
|
| Remote Intelligent Perception Technology (RIPT) |
Support |
|
| X-speed |
Support |
|
| Intelligent load balancing based on the number of users or traffic |
Support |
|
| STA control |
SSID/radio-based |
|
| Bandwidth control |
STA/SSID/AP-based speed control |
|
| Preference for 5GHz (band select) |
Support |
|
| Wireless position tracking |
Support |
|
| Dynamic Frequency Selection(DFS) |
Future Release Support |
|
|
Security |
PSK, Web, and 802.1x authentication |
Support |
| Data encryption |
WPA (TKIP), WPA2 (AES), WPA-PSK, and WEP (64 or 128 bits) |
|
| SMS authentication |
Support |
|
| PEAP authentication |
Support |
|
| Data frame filtering |
Whitelist, static/dynamic blacklist |
|
| User isolation |
Support |
|
| Rogue AP detection and countermeasure |
Support |
|
| Dynamic ACL assignment |
Support |
|
| RADIUS |
Support |
|
| Wireless Intrusion Detection System(WIDS) |
Support |
|
| Wireless Intrusion Prevention System (WIPS) |
Support |
|
| Bluetooth | iBeacon |
Support |
| Routing | IPv4 address |
Static IP address or DHCP reservation |
| IPv6 CAPWAP tunnel |
Support |
|
| ICMPv6 |
Support |
|
| IPv6 address |
Manual or automatic configuration |
|
| Multicast |
Multicast to unicast conversion |
|
| Management and Maintenance | Network management |
SNMP v1/v2C/v3, Telnet, TFTP, Web management |
| One-click Optimization |
Support |
|
|
(need to integrate with WIS) |
||
| Fault detection and alarm |
Support |
|
| Cloud AC management |
Support |
|
| Statistics and logs |
Support |
|
| FAT/FIT switching |
The AP working in FIT mode can switch to the FAT mode through the RG-WS wireless AC. |
|
|
The AP working in FAT mode can switch to the FIT mode through a local console port or Telnet. |
||
| External Characteristics | Lock |
Support |
| LED Indicators |
1 LED (red, green, blue, orange, and flashing modes, breathing flashing mode for smart device access, and the indicator can be switched off to silent mode) |
|
| Relevant Standard | Wi-Fi Alliance Certification |
Support |
| Safety Standard |
GB4943, EN/IEC 60950-1 |
|
| EMC Standard |
GB9254, EN301 489 |
|
| Health Standard |
EN 62311 |
|
| Radio Standard |
EN300 328, EN301 893 |
|
| Vibration Standard |
IEC60068 2-31, ETSI EN300 019, |
|
|
NEBS GR-63-CORE |
||
|
|
Dimensions (W x D x H) (mm) |
180 × 180 × 20 |
|
Specifications |
(Height of AP only, excluding case and mount kit) |
|
| Weight |
0.37kg |
|
| Work Environment | Temperature |
Operating Temperature: -10°C to 50°C |
|
Storage Temperature: -40°C to 70°C |
||
| Humidity |
Operating Humidity: 5% to 95% (non-condensing) |
|
|
Storage Humidity: 5% to 95% (non-condensing) |
||
| Installation Mode |
Ceiling/wall-mountable |
|
